China 12VDC 96W 100W Laptop Desktop Adaptor Power Adapter

Product Description

12vdc 96w 100w laptop desktop adaptor power adapter 12 volt ac dc 8amp

SPECIFICATION SHEET:

Item: Desktop Power Adapter Input Voltage: 100V - 240V AC / 47Hz - 63HzOutput Voltage: 8V-48V Output Current: 0.1-5.0AmpProtection:Short-circuit ProtectionOver-current ProtectionOver-voltage ProtectionOver-temperature protectionWarranty: 1 yearTesting:Burn-in test: 4H x 80-100% rated load @ 40±5°CMTBF: at least 20,000hours @ 25ºC, Full load. Height: 1m, the product should be fall off on the 20mm thick hardwood. Average fault-free times under 25°C maximum working load.Average fault-free time 50,000 hours (As per IEC60950 standards)

Data Sheet:

ITEM: Power Adapter

Item	AC DC Desktop Power Adapter
Input	100V - 240V AC / 47Hz - 63Hz
Output	12V DC / 8A
Load Regulation	±5%
Working Efficiency	Class VI
Ripple/Noise	100mV Min(P-P)
Inrush Current	15A Max @ 115V AC
Line Regulation	±1%
Operating Temperature	0 to 40°C
Storage Temperature	-10 to 70°C
DC Jack (Plug)	5.5mm x 2.1mm x 10mm 5.5mm x 2.5mm x 10mm 4.0mm x 1.7mm x 10mm 3.5mm x 1.35mm x 10mm
DC Cable Length	1.5/1.8/2.0/2.5/3.5m
Weight	235g
COLOR	Black/white
