Dali Dimming Push Dimmable 12V 24V 36V 48V 100W Dali 2 Dt8 LED Driver

Product Description

DALI 2 PUSH 24V 100W Dimmable LED Driver

Feature

·Output constant Voltage (NFC regulation)

·Range: 100-277VAC

·Built-in active PFC function

·Efficiency up to 88%

·Protections: short circuit/ over load/ over temperature

·IP66 waterproof design for indoor and outdoor installation

·Cooling by free air convection

·Dimming curve: Logarithmic (default) and Linear

·Dimming protocol: DALI Protocol IEC62386

·NFC function to adjust output voltage and set address

·Dimming range: 0-100%, LED start at 0.1% possible

·Suitable for intelligent LED lighting

Specification

Model		KV-12100-DP2-A	KV-24100-DP2-A	KV-12100-DP2-A	KV-24100-DP2-A
Output	DC Voltage (NFC regulation)	11.2-13V	23-25V	34.4-38V	46.4-50V
	Voltage Tolerance	±0.2V
	Voltage Regulation	±0.5%
	Rated current	8.34A	4.17A	2.78A	2.08A
	Rated power	100W
	Load Regulation	±2%
Input	Voltage Range	100-277VAC
	Frequency Range	47 - 63Hz
	Power Factor(Typ.)@ full load	PF≥0.98@120VAC PF≥0.96@230VAC PF≥0.95@277VACF≥0.98
	THD(Typ.)@ full load	<10%
	Efficiency(Typ.)@ full load	86%@120VAC 89%@230VAC/277VAC
	AC Current(Max.)	1.3A
	Inrush Current (Typ.)	36.4A (Twidth 164us measured at 50% I peak, COLD START, 230VAC)
	Leakage current	<0.5mA
Protection	Short Circuit	Hiccup mode, recover automatically after fault condition is removed
	Over Load	≤120% ,hiccup mode, recover automatically after fault condition is removed
	Over temperature	100ºC±10ºC Reduce output voltage, recovers automatically after temperature goes down
	Protection Class	2
